Product Summary

  • The EPM7064STI44-7N is a high-density, high-performance PLD. It is based on Altera’s second-generation MAX architecture.

Parametrics

Absolute maximum ratings: (1)Supply voltage:–2.0V to 7.0V; (2)DC input voltage:–2.0V to 7.0V; (3)DC output current, per pin:–25mA to 25mA; (4)Storage temperature:–65℃ to 150℃; (5)Ambient temperature:–65℃ to 135℃; (6)Junction temperature:Ceramic packages, under bias:150 ℃,PQFP and RQFP packages, under bias:135℃.

Features

Features: (1)High-performance, EEPROM-based programmable logic devices(PLDs)based on second-generation MAX architecture; (2)5.0-V in-system programmability (ISP) through the built-in IEEE Std. 1149.1 Joint Test Action Group (JTAG) interface available in MAX 7000S devices:ISP circuitry compatible with IEEE Std. 1532; (3)Includes 5.0-V MAX 7000 devices and 5.0-V ISP-based MAX 7000S devices; (4)Built-in JTAG boundary-scan test (BST) circuitry in MAX 7000S devices with 128 or more macrocells; (5)Complete EPLD family with logic densities ranging from 600 to 5,000 usable gates (see Tables 1 and 2); (6)5-ns pin-to-pin logic delays with up to 175.4-MHz counter frequencies (including interconnect); (7)PCI-compliant devices available.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EPM7064STI44-7N
EPM7064STI44-7N


IC MAX 7000 CPLD 64 44-TQFP

Data Sheet

0-1: $19.50
