Product Summary

  • The CD4001BE is a quad 2 input NOR gate. It provides the system designer with direct implementation of the NOR function and supplement the existing family of CMOS gates. All inputs and outputs are buffered.

Parametrics

CD4001BE absolute maximum ratings: (1)DC supply-votlage range, VDD, voltage reference to VSS terminal: -0.5 to 20V; (2)input voltage range, all inputs: -0.5 to VDD+0.5V; (3)DC input current, any one input: ±10mA; (4)power dissipation per package, PD: 500mW at TA=-55 to 100℃; (5)device dissipation per output transistor: 100mW; (6)operating temperature range, TA: -55 to 125℃; (7)storage temperature range, Tstg: -55 to 150℃; (8)lead temperature: 265℃.

Features

CD4001BE features: (1)propagation delay time=60ns typ at CL=50pF, VDD=10V; (2)buffered inputs and outputs; (3)standardized symmetrical output characteristics; (4)100% tested for maximum quiescent current at 20V; (5)5V, 10V and 15V parametric ratings; (6)maximum input current of 1μA at 18V over full package temperature range; 10nA at 18V and 25℃; (7)noise margin: 1V at VDD=5V; 2V at VDD=10V; 2.5V at VDD=15V; (8)meets all requirements of JEDEC tentative standard No 13B.

Diagrams

CD4001BE functional diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CD4001BE
CD4001BE

Texas Instruments

Gates (AND / NAND / OR / NOR) CMOS Quad 2-In

Data Sheet

0-1: $0.25
1-25: $0.21
25-100: $0.16
100-250: $0.16
CD4001BEE4
CD4001BEE4

Texas Instruments

Gates (AND / NAND / OR / NOR) CMOS Quad 2-In

Data Sheet

0-1: $0.30
1-25: $0.22
25-100: $0.19
100-250: $0.17
