Product Summary

  • The XC3S50AN-4TQG144C builds on the success of the earlier Spartan-IIE family by increasing the amount of logic resources, the capacity of internal RAM, the total number of I/Os, and the overall level of performance as well as by improving clock management functions. Numerous enhancements derive from state-of-the-art Virtex-II technology. The XC3S50AN-4TQG144C is combined with advanced process technology, deliver more functionality and bandwidth per dollar than was previously possible, setting new standards in the programmable logic industry. Because of its exceptionally low cost, XC3S50AN-4TQG144C is ideally suited to a wide range of consumer electronics applications, including broadband access, home networking, display/projection and digital television equipment.

Parametrics

XC3S50AN-4TQG144C absolute maximum ratings: (1)VCCINT Internal supply voltage relative to GND: min=-0.5V, max=1.32V; (2)VCCAUX Auxiliary supply voltage relative to GND: min=-0.5V, max=3.00V; (3)VCCO Output driver supply voltage relative to GND: min=-0.5V, max=3.75V; (4)VREF Input reference voltage relative to GND: min=-0.5V, max=VCCO+0.5(3)V; (5)On the condition of Driver in a high-impedance state, VIN(2) Voltage applied to all User I/O pins and Dual-Purpose pins relative to GND: min=-0.5V, max=VCCO+0.5(3)V; Voltage applied to all Dedicated pins relative to GND: min=-0.5V, max=VCCAUX+0.5V.

Features

XC3S50AN-4TQG144C features: (1)Low-cost, high-performance logic solution for high-volume,; (2)consumer-oriented applications; (3)SelectIO signaling; (4)Logic resourcess; (5)SelectRAM hierarchical memory; (6)Digital Clock Manager (up to four DCMs); (7)Digital Clock Manager (up to four DCMs).

Diagrams

XC3S50AN-4TQG144C

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC3S50AN-4TQG144C
XC3S50AN-4TQG144C


IC SPARTAN-3AN FPGA 50K 144TQFP

Data Sheet

0-1: $5.95
