Product Summary

  • The UA741CN is a high performance monolithic operational amplifier constructed on a single silicon chip. It is intended for a wide range of analog applications. The high gain and wide range of operating voltages provide superior performances in integrator, summing amplifier and general feedback applications. The internal compensation network (6 dB/octave) ensures stability in closedloop circuits. The applications of the UA741CN include Summing amplifiers, Voltage followers, Integrators, Active filters, Function generators.

Parametrics

UA741CN absolute maximum ratings: (1)supply voltage: 22V; (2)Input voltage: 15V; (3)differential input voltage: 30V; (4)power dissipation: 500mW; (5)operating free-air temperature range: 0 to 70℃; (6)storage temperature range: -65 to 150℃.

Features

UA741CN features: (1)Large input voltage range; (2)No latch-up; (3)High gain; (4)Short-circuit protection; (5)No frequency compensation required; (6)Same pin configuration as the UA709.

Diagrams

UA741CN diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UA741CN
UA741CN

STMicroelectronics

Operational Amplifiers - Op Amps Single General Purp

Data Sheet

0-1: $0.18
1-10: $0.17
10-100: $0.14
100-250: $0.11
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UA741
UA741

Other


Data Sheet

Negotiable
UA741CD
UA741CD

Texas Instruments

Operational Amplifiers - Op Amps GP Op Amp

Data Sheet

0-1: $0.31
1-25: $0.23
25-100: $0.19
100-250: $0.17
UA741CDE4
UA741CDE4

Texas Instruments

Operational Amplifiers - Op Amps General-Purpose Op Amp

Data Sheet

0-1: $0.26
1-25: $0.21
25-100: $0.18
100-250: $0.15
UA741CDG4
UA741CDG4

Texas Instruments

Operational Amplifiers - Op Amps GP Op Amp

Data Sheet

0-1: $0.26
1-25: $0.21
25-100: $0.18
100-250: $0.15
UA741CDR
UA741CDR

Texas Instruments

Operational Amplifiers - Op Amps General-Purpose Op Amp

Data Sheet

0-1: $0.26
1-25: $0.19
25-100: $0.17
100-250: $0.14
UA741CDRE4
UA741CDRE4

Texas Instruments

Operational Amplifiers - Op Amps General-Purpose Op Amp

Data Sheet

0-1: $0.22
1-25: $0.17
25-100: $0.15
100-250: $0.13
