Product Summary
-
The KA3525A is an SMPS controller. It is a monolithic integrated circuit that includes all of the control circuits necessary for a pulse width modulating regulator. There are a voltage reference, an error amplifier, a pulse width modulator, an oscillator, an under voltage lockout, a soft start circuit, and the output driver in the chip.
Parametrics
KA3525A absolute maximum ratings: (1)supply voltage: 40V; (2)collector supply voltage: 40V; (3)output current: 500mA; (4)oscillator charging current: 5mA; (5)power dissipation: 1000m/W; (6)operating temperature: 0 to 70℃; (7)storage temperature: -65 to 150℃; (8)lead temperature: 300℃.
Features
KA3525A features: (1)5V ±1% Reference; (2)Oscillator Sync Terminal; (3)Internal Soft Start; (4)Deadtime Control; (5)Under Voltage Lockout.
Diagrams
